Industrial Rack Mount LCD Monitor
Product Overview
Standard 19" rack mount monitors for server rooms, data centers, and industrial control cabinets. Easy installation with included mounting hardware.
Technical Specifications
| Models | 8.4" ~ 23.8" |
| IP Rating | IP65 / IP66 |
| Brightness | 250~350 NITS |
| Contrast | 600:1 ~ 1000:1 |
Key Selling Points
1000:1 Contrast
Superior contrast for clear data visualization in control rooms
Standard 19" Rack
Standard rack mount for server rooms and control cabinets
KVM Compatible
Optional KVM switch compatibility for efficient management
Control-Room Brightness
Measured 250-350 NITS across the range — matched to dim server rooms and network operations centres
Easy Installation
Included mounting hardware for quick rack deployment
Application Industries
Standard 19-inch rack form factor for server cabinet monitoring
1000:1 high contrast for clear system status visualization
Rack-mountable display for SCADA and process control systems
Reliable monitoring display for broadcast and media control rooms
KVM-compatible rack display for telecom network management
Competitive Advantages
Highest Contrast in Class
1000:1 outperforms typical 500:1-800:1 competitors — critical for control room readability.
Multi-Size Options
8.4", 10.4", 12.1", 15", 17", 19", 21.5" and 23.8" — eight models covering 1U telecom bays through wide SCADA console builds.
Remote Power Control
Optional remote power control for data center automation.
Certifications & Compliance
Available Models
8 models available
Available Sizes
Select a size for detailed specifications, applications, and quote
Model Selection Guide
Which model fits your project? Use the table below to identify the best match.
| Model | Size | Recommended For | Typical Scenario |
|---|---|---|---|
AP-084OPLR/8.4" | 8.4" | 1U telecom rack consoles, broadcast monitoring racks and SCADA overview racks | 800×600 4:3 content at 350 NITS across a 170.4×127.8 mm active area; -20 ~ 70 °C operation. Installed in server room KVM drawers and network operations center consoles, this 8.4" panel suits 1U telecom rack consoles — where rack depth and drawer travel set the limit. Within this family it sits between the 10.4" — choose this size for broadcast monitoring racks and SCADA overview racks. At roughly 119 PPI it renders 800×600 natively without scaling, and its 170.4 mm active width differs from the 10.4" at 211.2 mm — confirm against your cutout drawing |
AP-104OPLR/10.4" | 10.4" | Server room KVM drawers, network operations center consoles and 1U telecom rack consoles | 800×600 4:3 content at 300 NITS across a 211.2×158.4 mm active area; -20 ~ 70 °C operation. Installed in broadcast monitoring racks and SCADA overview racks, this 10.4" panel suits server room KVM drawers — where rack depth and drawer travel set the limit. Within this family it sits between the 8.4" and the 12.1" — choose this size for network operations center consoles and 1U telecom rack consoles. At roughly 96 PPI it renders 800×600 natively without scaling, and its 211.2 mm active width differs from the 8.4" at 170.4 mm and the 12.1" at 245.76 mm — confirm against your cutout drawing |
AP-12OPLR/12.1" | 12.1" | Compact server room KVM drawers, network rack monitoring and telecom cabinet displays | 1024×768 4:3 content at 350 NITS across a 245.76(W)×184.32(H) mm active area; -20 ~ 70 °C operation. 1U/2U rack drawer integration where depth is constrained; legacy frame size replacement |
AP-15IPLR/15" | 15" | Broadcast monitoring racks, SCADA overview racks and server room KVM drawers | 1024×768 4:3 content at 350 NITS across a 304.128×228.096 mm active area; -20 ~ 70 °C operation. Installed in network operations center consoles and 1U telecom rack consoles, this 15" panel suits broadcast monitoring racks — where rack depth and drawer travel set the limit. Within this family it sits between the 12.1" and the 17" — choose this size for SCADA overview racks and server room KVM drawers. At roughly 86 PPI it renders 1024×768 natively without scaling, and its 304.128 mm active width differs from the 12.1" at 245.76 mm and the 17" at 337.92 mm — confirm against your cutout drawing |
AP-17OPLR/17" | 17" | Network operations center consoles, 1U telecom rack consoles and broadcast monitoring racks | 1280×1024 4:3 content at 250 NITS across a 337.92×270.336 mm active area; 0 ~ 50 °C operation. Installed in SCADA overview racks and server room KVM drawers, this 17" panel suits network operations center consoles — where rack depth and drawer travel set the limit. Within this family it sits between the 15" and the 19" — choose this size for 1U telecom rack consoles and broadcast monitoring racks. At roughly 96 PPI it renders 1280×1024 natively without scaling, and its 337.92 mm active width differs from the 15" at 304.128 mm and the 19" at 374.784 mm — confirm against your cutout drawing |
AP-19OPLR/19" | 19" | Full-rack control consoles, NOC wall displays and industrial automation dashboards | 1280×1024 5:4 content at 250 NITS across a 374.784(W)×299.827(H) mm active area; 0 ~ 50 °C operation. Maximum visibility installations; multi-system monitoring from a single operator station |
AP-21OPLR/21.5" | 21.5" | SCADA overview racks, server room KVM drawers and network operations center consoles | 1920×1080 widescreen content at 250 NITS across a 476.64×268.11 mm active area; 0 ~ 50 °C operation. Installed in 1U telecom rack consoles and broadcast monitoring racks, this 21.5" panel suits SCADA overview racks — where rack depth and drawer travel set the limit. Within this family it sits between the 19" and the 23.8" — choose this size for server room KVM drawers and network operations center consoles. At roughly 102 PPI it renders 1920×1080 natively without scaling, and its 476.64 mm active width differs from the 19" at 374.784 mm and the 23.8" at 527.04 mm — confirm against your cutout drawing |
AP-238OPLR/23.8" | 23.8" | Multi-view broadcast monitoring walls, SCADA control room overview consoles and large rack-mount supervisory desks | 1920×1080 widescreen content at 250 NITS across a 527.04×296.46 mm active area; 0 ~ 50 °C operation. Installed in server room KVM drawers and network operations center consoles, this 23.8" panel suits 1U telecom rack consoles — where rack depth and drawer travel set the limit. Within this family it sits between the 21.5" — choose this size for broadcast monitoring racks and SCADA overview racks. At roughly 93 PPI it renders 1920×1080 natively without scaling, and its 527.04 mm active width differs from the 21.5" at 476.64 mm — confirm against your cutout drawing |
Our engineers provide free consultation to help you select the right model for your application.
Ask Our EngineerTechnical Resources & Support
Rack integration documentation, interface definitions and support policy
Need the datasheet, mechanical drawings or 3D model? We issue project-specific datasheets, drawings and 3D models for your configuration — typically within 24–48 hours.
Engineering Support
Our engineers help you select the right display for your application — free consultation.
Contact EngineerFast Response
Production Info
Shipping & Returns
Global delivery: 7-30 days. Contact for shipping quote.
30-day return policy. Negotiable based on product condition.
Send Product Inquiry
Complete the form below — our engineering team will respond with detailed specifications and pricing.
Frequently Asked Questions
Does this monitor fit in a standard 19" server rack?
Can I use a KVM switch with this monitor?
What IP rating does the rack mount monitor have?
Is remote power control supported?
Need a Custom Solution?
OEM/ODM customization available — size, brightness, touch type, bezel, and interface. No minimum order quantity.
